Model NO.: 32005 Bearing
Size: 25x47x15 mm
Material: Chrome Steel Gcr15
The Number of Rows:Single
Tolerance: P0 P4 P5 P2
Certification: ISO9001, IATF16949
Deliver Time: 0-15days
Origin: China
Product Overview
The Metric Tapered Roller Bearing 32005 is part of the 320 series, designed for high-load applications requiring reliable performance and durability. With an inner diameter of 25 mm, an outer diameter of 47 mm, and a width of 15 mm, this 32005 bearing features a tapered design that allows for effective load distribution, making it suitable for various industries, including automotive, machinery, and construction.
✅ Superior Load Capacity
Dual Load Handling: Supports combined radial and axial loads simultaneously
High Dynamic Load Rating: 28.5 kN (C) for extended operational life
Static Load Capacity: 30.5 kN (C0) for heavy-duty applications
✅ Precision Engineering
ISO 355:2007 Compliant: 32005 bearing meets international quality standards
Precision Ground Components: Reduced friction and vibration
Optimal Contact Angle: 12°-16° for efficient load distribution
✅ Durability & Reliability
High-Quality Chrome Steel (GCr15): Hardness HRC 58-62 for wear resistance
Heat-Treated Components: Enhanced fatigue strength
Zinc-Phosphate Coating: Corrosion protection in harsh environments
✅ Easy Installation & Maintenance
Standard Metric Dimensions: 25x47x15 mm for easy replacement
Interchangeable Design: 32005 bearing compatible with major brands
Clear Markings: Easy identification and installation
Industrial Machinery
Gearboxes and transmission systems
Conveyor systems and material handling equipment
Agricultural machinery and tractors
Construction equipment and heavy machinery
Automotive & Transportation
Wheel hubs and axle assemblies
Differential systems
Industrial vehicles and trailers
General Engineering
Pumps and compressors
Electric motors and generators
Machine tools and industrial robots
32005 bearing Basic Info.
Model NO. | 32005 | Load Direction | Bearing Steel |
Separated | Separated | Spherical | Non-Aligning Bearings |
Material | Bearing Steel | Application | Automobile |
Vibration | V1 | Noise Level | Z1 |
Roller Super Finishing | Yes | Raceway Super Finishing | Yes |
| Precision | P0 P5 P6 | Transport Package | Standard Exporting Packing |
Specification | Tapered Roller Bearing | Trademark | HECTO or OEM or neutral marking or no marking |
HS Code | 84822000 | Origin | China |
Production Capacity | 10 Million/Year |
32005 bearing Packaging & Delivery
Package Size | 28.00cm * 26.00cm * 17.00cm |
Package Gross Weight | 1.000kg |
Product Description
Basic Features of Tapered Roller Bearing | |
Types | 30200 series |
Material | Bearing Steel(GCr15, 100Cr6) |
Dimension | Metric and Inch |
Precision | P0 P5 P6 |
| Super finishing | Yes |
MOQ | 1 PC |
Delivery Time | 30-60 days |
Sea Ports | Shanghai Ningbo Qingdao |
Parameter | Value |
|---|---|
Bore Diameter (d) | 25 mm |
Outer Diameter (D) | 47 mm |
Width (B) | 15 mm |
Dynamic Load Rating (Cr) | 38.5 kN |
Static Load Rating (Cor) | 42.5 kN |
Speed Limit (Grease) | 6,000 rpm |
Speed Limit (Oil) | 8,000 rpm |
Weight | Approx. 0.12 kg |
Contact Angle | Approx. 12-16° |
Material | Chrome steel (SAE 52100 equivalent) |
Hardness | 58-64 HRC |
Operating Temperature | -30°C to +120°C |
Why Choose HECTO?
1. More than 20 years of manufacturing and exporting 32005 bearing experiences
2. an IATF16949 company
3. 100% inspecting of products
4. More competitive prices with better quality
5. More than 99% of delivery in time
6. Rapid response of your emails and questions
7. 32005 bearing products can be traced back
Some Metric Tapered Roller Bearings
BEARING NO. | d | D | T |
30202 | 15 | 35 | 11.75 |
30203 | 17 | 40 | 13.25 |
30204 | 20 | 47 | 15.25 |
30205 | 25 | 52 | 16.25 |
30206 | 30 | 62 | 17.25 |
30207 | 35 | 72 | 18.25 |
30208 | 40 | 80 | 19.25 |
30209 | 45 | 85 | 20.75 |
30210 | 50 | 90 | 21.75 |
30211 | 55 | 100 | 22.75 |
30212 | 60 | 110 | 23.75 |
30213 | 65 | 120 | 24.75 |
30214 | 70 | 125 | 26.25 |
30215 | 75 | 130 | 27.25 |
30216 | 80 | 140 | 28.25 |
30217 | 85 | 150 | 30.5 |
30218 | 90 | 160 | 32.5 |
30219 | 95 | 170 | 34.5 |
30220 | 100 | 180 | 37 |
30221 | 105 | 190 | 39 |
30222 | 110 | 200 | 41 |
30224 | 120 | 215 | 43.5 |
30226 | 130 | 230 | 43.75 |
30228 | 140 | 250 | 45.75 |
30230 | 150 | 270 | 49 |
30232 | 160 | 290 | 52 |
30234 | 170 | 310 | 57 |
30236 | 180 | 320 | 57 |
30238 | 190 | 340 | 60 |
30240 | 200 | 360 | 64 |
30302 | 15 | 42 | 14.25 |
30303 | 17 | 47 | 15.25 |
30304 | 20 | 52 | 16.25 |
30305 | 25 | 62 | 18.25 |
30306 | 30 | 72 | 20.75 |
30307 | 35 | 80 | 22.75 |
30308 | 40 | 90 | 25.25 |
30309 | 45 | 100 | 27.25 |
30310 | 50 | 110 | 29.25 |
30311 | 55 | 120 | 31.5 |
30312 | 60 | 130 | 33.5 |
30313 | 65 | 140 | 36 |
30314 | 70 | 150 | 38 |
30315 | 75 | 160 | 40 |
30316 | 80 | 170 | 42.5 |
30317 | 85 | 180 | 44.5 |
30318 | 90 | 190 | 46.5 |
30319 | 95 | 200 | 49.5 |
30320 | 100 | 215 | 51.5 |
30321 | 105 | 225 | 53.5 |
30322 | 110 | 240 | 54.5 |
30324 | 120 | 260 | 59.5 |
30326 | 130 | 280 | 63.75 |
30328 | 140 | 300 | 67.75 |
30330 | 150 | 320 | 72 |
30352 | 260 | 540 | 114 |
31305 | 25 | 62 | 18.25 |
31306 | 30 | 72 | 20.75 |
31307 | 35 | 80 | 22.75 |
31308 | 40 | 90 | 25.25 |
31309 | 45 | 100 | 27.25 |
31310 | 50 | 110 | 29.25 |
31311 | 55 | 120 | 31.5 |
31312 | 60 | 130 | 33.5 |
31313 | 65 | 140 | 36 |
31314 | 70 | 150 | 38 |
31315 | 75 | 160 | 40 |
31316 | 80 | 170 | 42.5 |
31317 | 85 | 180 | 44.5 |
320/22 | 22 | 44 | 15 |
320/28 | 28 | 52 | 16 |
320/32 | 32 | 58 | 17 |
32004 | 20 | 42 | 15 |
32005 | 25 | 47 | 15 |
32006 | 30 | 55 | 17 |
32007 | 35 | 62 | 18 |
32008 | 40 | 68 | 19 |
32009 | 45 | 75 | 20 |
32010 | 50 | 80 | 20 |
32011 | 55 | 90 | 23 |
32012 | 60 | 95 | 23 |
32013 | 65 | 100 | 23 |
32014 | 70 | 110 | 25 |
32015 | 75 | 115 | 25 |
32016 | 80 | 125 | 29 |
32017 | 85 | 130 | 29 |
32018 | 90 | 140 | 32 |
32019 | 95 | 145 | 32 |
32020 | 100 | 150 | 32 |
32021 | 105 | 160 | 35 |
32022 | 110 | 170 | 38 |
32024 | 120 | 180 | 38 |
32026 | 130 | 200 | 45 |
32028 | 140 | 210 | 45 |
32030 | 150 | 225 | 48 |
32032 | 160 | 240 | 51 |
32034 | 170 | 260 | 57 |
32205 | 25 | 52 | 19.5 |
32206 | 30 | 62 | 21.25 |
32207 | 35 | 72 | 24.25 |
32208 | 40 | 80 | 24.75 |
32209 | 45 | 85 | 24.75 |
32210 | 50 | 90 | 24.75 |
32211 | 55 | 100 | 26.75 |
32212 | 60 | 110 | 29.75 |
32213 | 65 | 120 | 32.75 |
32214 | 70 | 125 | 33.25 |
32215 | 75 | 130 | 33.25 |
32216 | 80 | 140 | 35.25 |
32217 | 85 | 150 | 38.5 |
32218 | 90 | 160 | 42.5 |
32219 | 95 | 170 | 45.5 |
32220 | 100 | 180 | 49 |
32221 | 105 | 190 | 53 |
32222 | 110 | 200 | 56 |
32224 | 120 | 215 | 61.5 |
32226 | 130 | 230 | 67.75 |
32228 | 140 | 250 | 71.75 |
32230 | 150 | 270 | 77 |
32232 | 160 | 290 | 84 |
32234 | 170 | 310 | 91 |
32236 | 180 | 320 | 91 |
32238 | 190 | 340 | 97 |
32240 | 200 | 360 | 104 |
32244 | 220 | 400 | 114 |
32303 | 17 | 47 | 20.25 |
32304 | 20 | 52 | 22.25 |
32305 | 25 | 62 | 25.25 |
32306 | 30 | 72 | 28.75 |
32307 | 35 | 80 | 32.75 |
32308 | 40 | 90 | 35.25 |
32309 | 45 | 100 | 38.25 |
32310 | 50 | 110 | 42.25 |
32311 | 55 | 120 | 45.5 |
32312 | 60 | 130 | 48.5 |
32313 | 65 | 140 | 51 |
32314 | 70 | 150 | 54 |
32315 | 75 | 160 | 58 |
32316 | 80 | 170 | 61.5 |
32317 | 85 | 180 | 63.5 |
32318 | 90 | 190 | 67.5 |
32319 | 95 | 200 | 71.5 |
32320 | 100 | 215 | 77.5 |
32321 | 105 | 225 | 81.5 |
32322 | 110 | 240 | 84.5 |
32324 | 120 | 260 | 90.5 |
32330 | 150 | 320 | 114 |
32907 | 35 | 55 | 14 |
32908 | 40 | 62 | 15 |
32909 | 45 | 68 | 15 |
32910 | 50 | 72 | 15 |
32911 | 55 | 80 | 17 |
32912 | 60 | 85 | 17 |
32913 | 65 | 90 | 17 |
32914 | 70 | 100 | 20 |
32915 | 75 | 105 | 20 |
32916 | 80 | 110 | 20 |
33005 | 25 | 47 | 17 |
33006 | 30 | 55 | 20 |
33007 | 35 | 62 | 21 |
33008 | 40 | 68 | 22 |
33009 | 45 | 75 | 24 |
33010 | 50 | 80 | 24 |
33011 | 55 | 90 | 27 |
33012 | 60 | 95 | 27 |
33013 | 65 | 100 | 27 |
33014 | 70 | 110 | 31 |
33017 | 85 | 130 | 36 |
33018 | 90 | 140 | 39 |
33113 | 65 | 110 | 34 |
33116 | 80 | 130 | 37 |
33117 | 85 | 140 | 41 |
33119 | 95 | 160 | 49 |
332/28 | 28 | 58 | 24 |
332/32 | 32 | 65 | 26 |
33206 | 30 | 62 | 25 |
33207 | 35 | 72 | 28 |
33208 | 40 | 80 | 32 |
33209 | 45 | 85 | 32 |
33210 | 50 | 90 | 32 |
33212 | 60 | 110 | 38 |
